Download | kitagawa B-200M series

Type	Instruction Manual	Outline Drawing	-
B-206M	PDF	PDF DXF DWG Parasolid STEP	Parasolid STEP
B-208M	PDF	PDF DXF DWG Parasolid STEP	Parasolid STEP
B-210M	PDF	PDF DXF DWG Parasolid STEP	Parasolid STEP

Note) The blue 3D data represents the jaw positions at the fully open (UC) and fully closed (OC) ends for both Parasolid and STEP.
The pink 3D data represents the jaw positions at the centre of stroke (HCL), the appropriate open end (HOL) and the appropriate closed end (HUL) for both Parasolid and STEP.

Jaw stroke — A stroke mark to check the jaw stroke position is stamped on the No. 1 jaw part on the body. When the jaw is at the open end, the base line of the master jaw is aligned with the outer line of the full stroke range as shown in Figure 11. The base line moves across the full stroke range when the jaw is opened / closed. However, the base line must be within the appropriate stroke range when the chuck grips a workpiece.
