| Model | B-206M | B-208M | B-210M | |
|---|---|---|---|---|
| Through-hole (mm) | 45 | 52 | 75 | |
| Gripping Range (mm) | Max. | 169 | 210 | 254 |
| Min. | 7 | 9 | 25 | |
| Jaw Stroke (Diameter) (mm) | 5.5 | 7.4 | 8.8 | |
| Plunger Stroke (mm) | 12 | 16 | 19 | |
| Max. Draw Bar Pull Force (kN) | at OD Gripping | 21.4 | 34 | 40.6 |
| at ID Gripping | 10.7 | 17 | 20.3 | |
| Max. Static Gripping Force (kN) | at OD Gripping | 57 | 87 | 111 |
| at ID Gripping | 28.5 | 43.5 | 55.5 | |
| Max. Speed (min⁻¹) | 6000 | 5000 | 4200 | |
| Dynamic Gripping Force at Max. Speed (kN) (at OD Gripping) | 21.4 | 32.9 | 41.9 | |
| Moment of Inertia (kg·m²) | 0.047 | 0.13 | 0.33 | |
| Net Weight (kg) (with Soft Top Jaws) | 12.5 | 22.3 | 36.6 | |
| Matching Cylinder | S1246 | S1552 | S1875 | |
| Matching Hard Jaws Note) Jaw-mounting bolts are not included. |
HB06A1 HB06B1 |
HB08A1 | HB10A1 | |
| Matching Soft Jaws Note) Jaw‑mounting bolts are not included. |
Standard Extra Tall |
Standard Extra Tall |
Standard Extra Tall |
|
